Sanghvi Metals is a renowned engineering company famous for supplying SA 516 GR.70 Steel Plate in standard and non-standard sizes and specifications. These plates are mainly reliable for pressure vessels and boilers. SA 516 GR.70 steel grade consists of different elements like phosphorous, manganese, sulfur, chromium, carbon, and silicon that offer excellent chemical and mechanical properties. This grade provides exceptional resistance to corrosion and oxidation in any hostile environment. SA 516 GR.70 Steel Plates shows high resistance to work in pitting, crevice corrosion and stress corrosion in chloride and acidic solutions. These plates are easily welded and fabricated into different forms as per the needs. These plates are available in various types, shapes, and sizes as per the need of applications. Our SMO plates have excellent toughness and yield strength to sustain easily in higher temperature and pressure environments.
We at Sanghvi Metals have acquired a team of highly experienced and skilled professionals. Additionally, the group of production staff helps in producing optimum quality SA 516 GR.70 Steel Plates. The designing and development of plates according to international and national standards and specifications. Our expert fabricates these SA 516 GR.70 Steel Plates with proper care and modern tools and testing techniques. For avoiding product errors, our experts monitor each production step and assist production staff in bringing out the best quality products. We provide SMO plates to work smoothly in harsh and corrosive conditions. Our company offers SA 516 GR.70 Steel Plates at very competitive rates to worldwide customers. Our plates are highly in demand in numerous industries like oil and gas processing, petrochemical, pharmaceutical, chemical industries, and many more.
Specifications : ASTM A516 / ASME SA516
Grade : ASME SA 537 Gr.70 Boiler and Pressure Vessel Steel Plates
Thickness : 5mm-150mm
Width : 1000mm-4500mm
Length : 3000mm-18000mm
Impact tested : -52° C
Tempering : Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F.
British Standard | European Norm | ASTM/ASME | DIN |
BS1501-224-490A/B | EN10028 P355GH | A/SA516 - Grade 70 | - |
C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
0.18 | 0.4 | 0.95/1.50 | 0.015 | 0.008 | 0.02 (Min) | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
Tensile strength (ksi) | Yield strength (ksi) | Elongation min, % 200 mm (8 in) | Elongation min, % 50 mm (2 in) |
485-620 (70-90) | 260 (38) | 17 | 21 |
